Bearing
No. | Dimensions mm
inch | Bolt Size
mm
inch |
d | a | p | e | i | s | j | k | g | f | z | B | n |
UCFC201
UCFC201-8 | 12
1/2 | 100
3-15/16 | 78
3-5/16 | 55.1
2-11/64 | 10
15/32 | 12
15/32 | 5
13/64 | 7
9/32 | 20.5
13/16 | 62
2.4409 | 28.3
1-1/8 | 31
1.2205 | 12.7
0.500 | M10
3/8 |
UCFC202
UCFC202-9
UCFC202-10 | 15
9/16
5/8 | 100
3-15/16 | 78
3-5/16 | 55.1
2-11/64 | 10
15/32 | 12
15/32 | 5
13/64 | 7
9/32 | 20.5
13/16 | 62
2.4409 | 28.3
1-1/8 | 31
1.2205 | 12.7
0.500 | M10
3/8 |
UCFC203
UCFC203-11 | 17
11/16 | 100
3-15/16 | 78
3-5/16 | 55.1
2-11/64 | 10
15/32 | 12
15/32 | 5
13/64 | 7
9/32 | 20.5
13/16 | 62
2.4409 | 28.3
1-1/8 | 31
1.2205 | 12.7
0.500 | M10
3/8 |
UCFC204
UCFC204-12 | 20
3/4 | 100
3-15/16 | 78
3-5/16 | 55.1
2-11/64 | 10
15/32 | 12
15/32 | 5
13/64 | 7
9/32 | 20.5
13/16 | 62
2.4409 | 28.3
1-1/8 | 31
1.2205 | 12.7
0.500 | M10
3/8 |
UCFC205
UCFC205-13
UCFC205-14
UCFC205-15
UCFC205-16 | 25
13/16
7/8
15/16
1 | 115
4-17/32 | 90
3-35/64 | 63.6
2-1/2 | 10
15/32 | 12
15/32 | 6
15/64 | 7
9/32 | 21
53/64 | 70
2.7559 | 29.8
1-11/64 | 34.1
1.3425 | 14.3
0.563 | M10
3/8 |
UCFC206
UCFC206-17
UCFC206-18
UCFC206-19
UCFC206-20 | 30
1-1/16
1-1/8
1-3/16
1-1/4 | 125
4-59/64 | 100
3-15/16 | 70.7
2-25/32 | 10
15/32 | 12
15/32 | 8
5/16 | 8
5/16 | 23
29/32 | 80
3.1496 | 32.2
1-17/64 | 38.1
1.5000 | 15.9
0.626 | M10
3/8 |
UCFC207
UCFC207-20
UCFC207-21
UCFC207-22
UCFC207-23 | 35
1-1/4
1-5/16
1-3/8
1-7/16 | 135
2-5/16 | 110
4-21/64 | 77.8
3-1/16 | 11
7/16 | 14
35/64 | 8
5/16 | 9
23/64 | 26
1-1/32 | 90
3.5433 | 36.4
1-7/16 | 42.9
1.6890 | 17.5
0.689 | M12
7/16 |
UCFC208
UCFC208-24
UCFC208-25 | 40
1-1/2
1-9/16 | 145
5-45/64 | 120
4-23/32 | 84.8
3-11/32 | 11
7/16 | 14
35/64 | 10
25/64 | 9
23/64 | 26
1-1/32 | 100
3.9370 | 41.2
1-5/8 | 49.2
1.9370 | 19
0.748 | M12
7/16 |
UCFC209
UCFC209-26
UCFC209-27
UCFC209-28 | 45
1-5/8
1-11/16
1-3/4 | 160
6-19/64 | 132
5--13/64 | 93.3
3-43/64 | 10
25/64 | 16
5/8 | 12
15/32 | 14
35/64 | 26
1-1/32 | 105
4.1339 | 40.2
1-37/64 | 49.2
1.9370 | 19
0.748 | M14
1/2 |
UCFC210
UCFC210-29
UCFC210-30
UCFC210-31
UCFC210-32 | 50
1-13/16
1-7/8
1-15/16
2 | 165
6-1/2 | 138
5-7/16 | 97.6
3-27/32 | 10
25/64 | 16
5/8 | 12
15/32 | 14
35/64 | 28
1-7/64 | 110
4.3307 | 42.6
1-11/16 | 51.6
2.0315 | 19
0.748 | M14
1/2 |
UCFC211
UCFC211-32
UCFC211-33
UCFC211-34
UCFC211-35 | 55
2
2-1/16
2-1/8
2-3/16 | 185
6-1/2 | 150
5-29/32 | 106.1
4-3/16 | 13
33/64 | 19
3/4 | 12
15/32 | 15
19/32 | 31
1-7/32 | 125
4.9213 | 46.4
1-53/64 | 55.6
2.1890 | 22.2
0.874 | M16
5/8 |
UCFC212
UCFC212-36
UCFC212-37
UCFC212-38
UCFC212-39 | 60
2-1/4
2-5/16
2-3/8
2-7/16 | 195
7-11/16 | 160
6-19/64 | 113.1
4-29/64 | 17
43/64 | 19
3/4 | 12
15/32 | 15
19/32 | 36
1-27/64 | 135
5.3150 | 56.7
2-15/64 | 65.1
2.5630 | 25.4
1.000 | M16
5/8 |
UCFC213
UCFC213-40
UCFC213-41 | 65
2-1/2
2-9/16 | 205
8-5/64 | 170
6-11/16 | 120.2
4-47/64 | 16
5/8 | 19
3/4 | 14
35/64 | 15
19/32 | 36
1-27/64 | 145
5.5118 | 55.7
1-3/16 | 65.1
2.5630 | 25.4
1.000 | M16
5/8 |
UCFC214
UCFC214-42
UCFC214-43
UCFC214-44 | 70
2-5/8
2-11/16
2-3/4 | 215
8-15/32 | 177
6-31/32 | 125.1
4-59/64 | 17
43/64 | 19
3/4 | 14
35/64 | 18
19/32 | 40
1-37/64 | 150
5.9055 | 61.4
1-13/32 | 74.6
2.9370 | 30.2
1.189 | M16
5/8 |
UCFC215
UCFC215-45
UCFC215-46
UCFC215-47
UCFC215-48 | 75
2-13/16
2-7/8
2-15/16
3 | 220
8-21/32 | 184
7-1/4 | 130.1
5-1/8 | 18
23/32 | 19
3/4 | 16
5/8 | 18
19/32 | 40
1-37/64 | 160
6.2992 | 62.5
2-15/32 | 77.8
3.0630 | 33.3
1.311 | M16
5/8 |
UCFC216
UCFC216-49
UCFC216-50
UCFC216-51 | 80
3-1/16
3-1/8
3-3/16 | 240
9-29/64 | 200
7-7/8 | 141.4
5-9/16 | 18
23/32 | 23
29/32 | 16
5/8 | 18
19/32 | 42
1-21/32 | 170
6.6929 | 67.3
2-21/32 | 82.6
3.2520 | 33.3
1.311 | M20
3/4 |
UCFC217
UCFC217-52
UCFC217-53
UCFC217-55 | 85
3-1/16
3-5/16
3-7/16 | 250
9-27/32 | 208
8-3/16 | 147.1
5-51/64 | 18
23/32 | 23
29/32 | 18
23/32 | 20
25/32 | 45
1-25/32 | 180
7.0866 | 69.6
2-3/4 | 85.7
3.3740 | 34.1
1.343 | M20
3/4 |
UCFC218
UCFC218-56 | 90
3-1/2 | 265
10-7/16 | 220
8-21/32 | 155.5
6-1/8 | 22
55/64 | 23
29/32 | 18
23/32 | 20
25/32 | 50
1-31/32 | 190
7.4803 | 78.3
3-3/32 | 96
3.7795 | 39.7
1.5630 | M20
3/4 |
