Bearing NO. | Dimensions(mm/in.) | Weight(kg) | ||||||||||
d | D | B1 | B | C | S | Ds | G | B5 | D3 | F | ||
HC201 | 12 | 47 | 43.7 | 34.2 | 17 | 17.1 | M6x1 | 4.8 | 13.5 | 33.3 | 3.7 | 0.29 |
HC 201-8 | 1/2 | 1.8504 | 1.72 | 1.3465 | 0.6693 | 0.673 | 1/4-28UNF | 0.189 | 0.531 | 1.311 | 0.146 | 0.29 |
HC202 | 15 | 1.8504 | 1.72 | 1.3465 | 0.6693 | 0.673 | 1/4-28UNF | 0.189 | 0.531 | 1.311 | 0.146 | 0.27 |
HC 202-9 | 9/16 | 1.8504 | 1.72 | 1.3465 | 0.6693 | 0.673 | 1/4-28UNF | 0.189 | 0.531 | 1.311 | 0.146 | 0.26 |
HC 202-10 | 5/8 | 1.8504 | 1.72 | 1.3465 | 0.6693 | 0.673 | 1/4-28UNF | 0.189 | 0.531 | 1.311 | 0.146 | 0.26 |
HC203 | 17 | 1.8504 | 1.72 | 1.3465 | 0.6693 | 0.673 | 1/4-28UNF | 0.189 | 0.531 | 1.311 | 0.146 | 0.25 |
HC 203-11 | 11/16 | 1.8504 | 1.72 | 1.3465 | 0.6693 | 0.673 | 1/4-28UNF | 0.189 | 0.531 | 1.311 | 0.146 | 0.25 |
HC204 | 20 | 47 | 43.7 | 34.2 | 17 | 17.1 | M6x1 | 4.8 | 13.5 | 33.3 | 3.7 | 0.21 |
HC 204-12 | 3/4 | 1.8504 | 1.72 | 1.3465 | 0.6693 | 0.673 | 1/4-28UNF | 0.189 | 0.531 | 1.311 | 0.146 | 0.21 |
HC205 | 25 | 52 | 44.4 | 34.9 | 17 | 17.5 | M6x1 | 4.8 | 13.5 | 38.1 | 3.9 | 0.25 |
HC 205-13 | 13/16 | 2.0472 | 1.748 | 1.374 | 0.6693 | 0.689 | 1/4-28UNF | 0.189 | 0.531 | 1.5 | 0.154 | 0.3 |
HC 205-14 | 7/8 | 2.0472 | 1.748 | 1.374 | 0.6693 | 0.689 | 1/4-28UNF | 0.189 | 0.531 | 1.5 | 0.154 | 0.29 |
HC 205-15 | 15/16 | 2.0472 | 1.748 | 1.374 | 0.6693 | 0.689 | 1/4-28UNF | 0.189 | 0.531 | 1.5 | 0.154 | 0.27 |
HC 205-16 | 1 | 2.0472 | 1.748 | 1.374 | 0.6693 | 0.689 | 1/4-28UNF | 0.189 | 0.531 | 1.5 | 0.154 | 0.25 |
HC206 | 30 | 62 | 48.4 | 36.5 | 19 | 18.3 | M8x1 | 6 | 15.9 | 44.5 | 5 | 0.37 |
HC 206-17 | 1/16 | 2.4409 | 1.906 | 1.437 | 0.748 | 0.72 | 5/16-24UNF | 0.236 | 0.626 | 1.752 | 0.197 | 0.42 |
HC 206-18 | 1/8 | 2.4409 | 1.906 | 1.437 | 0.748 | 0.72 | 5/16-24UNF | 0.236 | 0.626 | 1.752 | 0.197 | 0.39 |
HC 206-19 | 3/16 | 2.4409 | 1.906 | 1.437 | 0.748 | 0.72 | 5/16-24UNF | 0.236 | 0.626 | 1.752 | 0.197 | 0.37 |
HC 206-20 | 1/4 | 2.4409 | 1.906 | 1.437 | 0.748 | 0.72 | 5/16-24UNF | 0.236 | 0.626 | 1.752 | 0.197 | 0.34 |
HC207 | 35 | 72 | 51.1 | 37.6 | 20 | 18.8 | M8x1 | 6.8 | 17.5 | 55.6 | 5.7 | 0.58 |
HC 207-20 | 1/4 | 2.8346 | 2.012 | 1.4803 | 0.7874 | 0.74 | 5/16-24UNF | 0.268 | 0.689 | 2.189 | 0.224 | 0.65 |
HC 207-21 | 5/16 | 2.8346 | 2.012 | 1.4803 | 0.7874 | 0.74 | 5/16-24UNF | 0.268 | 0.689 | 2.189 | 0.224 | 0.61 |
HC 207-22 | 3/8 | 2.8346 | 2.012 | 1.4803 | 0.7874 | 0.74 | 5/16-24UNF | 0.268 | 0.689 | 2.189 | 0.224 | 0.58 |
HC 207-23 | 7/16 | 2.8346 | 2.012 | 1.4803 | 0.7874 | 0.74 | 5/16-24UNF | 0.268 | 0.689 | 2.189 | 0.224 | 0.56 |
HC208 | 40 | 80 | 56.3 | 42.8 | 21 | 21.4 | M8x1 | 6.8 | 18.3 | 60.3 | 6.2 | 0.73 |
HC 208-24 | 1/2 | 3.1496 | 2.217 | 1.685 | 0.8268 | 0.843 | 5/16-24UNF | 0.268 | 0.72 | 2.374 | 0.244 | 0.78 |
HC 208-25 | 9/16 | 3.1496 | 2.217 | 1.685 | 0.8268 | 0.843 | 5/16-24UNF | 0.268 | 0.72 | 2.374 | 0.244 | 0.74 |
HC209 | 45 | 85 | 56.3 | 42.8 | 22 | 21.4 | M8x1 | 6.8 | 18.3 | 63.5 | 6.4 | 0.78 |
HC 209-26 | 5/8 | 3.3465 | 2.217 | 1.685 | 0.8661 | 0.843 | 5/16-24UNF | 0.268 | 0.72 | 2.5 | 0.252 | 0.89 |
HC 209-27 | 11/16 | 3.3465 | 2.217 | 1.685 | 0.8661 | 0.843 | 5/16-24UNF | 0.268 | 0.72 | 2.5 | 0.252 | 0.84 |
HC 209-28 | 3/4 | 3.3465 | 2.217 | 1.685 | 0.8661 | 0.843 | 5/16-24UNF | 0.268 | 0.72 | 2.5 | 0.252 | 0.8 |
HC210 | 50 | 90 | 62.7 | 49.2 | 24 | 24.6 | M8x1 | 6.8 | 18.3 | 69.9 | 6.5 | 0.94 |
HC 210-29 | 1-13/16 | 3.5433 | 2.469 | 1.937 | 0.9449 | 0.969 | 5/16-24UNF | 0.268 | 0.72 | 2.752 | 0.256 | 1.09 |
HC 210-30 | 7/8 | 3.5433 | 2.469 | 1.937 | 0.9449 | 0.969 | 5/16-24UNF | 0.268 | 0.72 | 2.752 | 0.256 | 1.03 |
HC 210-31 | 1-15/16 | 3.5433 | 2.469 | 1.937 | 0.9449 | 0.969 | 5/16-24UNF | 0.268 | 0.72 | 2.752 | 0.256 | 0.97 |
HC 210-32 | 2 | 3.5433 | 2.469 | 1.937 | 0.9449 | 0.969 | 5/16-24UNF | 0.268 | 0.72 | 2.752 | 0.256 | 0.91 |
HC211 | 55 | 100 | 71.4 | 55.5 | 25 | 27.8 | M10x1 | 8 | 20.7 | 76.2 | 7 | 1.26 |
HC 211-32 | 2 | 3.937 | 2.811 | 2.185 | 0.9843 | 1.094 | 3/8-24UNF | 0.315 | 0.815 | 3 | 0.276 | 1.46 |
HC 211-33 | 1/16 | 3.937 | 2.811 | 2.185 | 0.9843 | 1.094 | 3/8-24UNF | 0.315 | 0.815 | 3 | 0.276 | 1.38 |
HC 211-34 | 1/8 | 3.937 | 2.811 | 2.185 | 0.9843 | 1.094 | 3/8-24UNF | 0.315 | 0.815 | 3 | 0.276 | 1.31 |
HC 211-35 | 3/16 | 3.937 | 2.811 | 2.185 | 0.9843 | 1.094 | 3/8-24UNF | 0.315 | 0.815 | 3 | 0.276 | 1.23 |
HC212 | 60 | 110 | 77.8 | 61.9 | 27 | 31 | M10x1 | 8 | 22.3 | 84.2 | 7.6 | 1.71 |
HC 212-36 | 1/4 | 4.3307 | 3.063 | 2.437 | 1.063 | 1.22 | 3/8-24UNF | 0.315 | 0.878 | 3.315 | 0.299 | 1.73 |
HC 212-37 | 5/16 | 4.3307 | 3.063 | 2.437 | 1.063 | 1.22 | 3/8-24UNF | 0.315 | 0.878 | 3.315 | 0.299 | 1.78 |
HC 212-38 | 3/8 | 4.3307 | 3.063 | 2.437 | 1.063 | 1.22 | 3/8-24UNF | 0.315 | 0.878 | 3.315 | 0.299 | 1.71 |
HC 212-39 | 7/16 | 4.3307 | 3.063 | 2.437 | 1.063 | 1.22 | 3/8-24UNF | 0.315 | 0.878 | 3.315 | 0.299 | 1.71 |
HC213 | 65 | 120 | 85.7 | 68.6 | 28 | 34.1 | M10x1 | 8.5 | 23.5 | 86 | 8.5 | 2.24 |
HC 213-40 | 1/2 | 4.7244 | 3.374 | 2.7008 | 1.1024 | 1.343 | 3/8-24UNF | 0.335 | 0.925 | 3.386 | 0.335 | 1.8 |
HC 213-41 | 9/16 | 4.7244 | 3.374 | 2.7008 | 1.1024 | 1.343 | 3/8-24UNF | 0.335 | 0.925 | 3.386 | 0.335 | 2.23 |
HC214 | 70 | 125 | 85.7 | 68.6 | 29 | 34.1 | M10x1 | 8.5 | 23.5 | 90 | 8.9 | 2.35 |
HC 214-42 | 5/8 | 4.9213 | 3.374 | 2.7008 | 1.1417 | 1.343 | 3/8-24UNF | 0.335 | 0.925 | 3.543 | 0.35 | 2.29 |
HC 214-43 | 11/16 | 4.9213 | 3.374 | 2.7008 | 1.1417 | 1.343 | 3/8-24UNF | 0.335 | 0.925 | 3.543 | 0.35 | 2.48 |
HC 214-44 | 3/4 | 4.9213 | 3.374 | 2.7008 | 1.1417 | 1.343 | 3/8-24UNF | 0.335 | 0.925 | 3.543 | 0.35 | 2.36 |
HC215 | 75 | 130 | 92.1 | 75 | 30 | 37.3 | M10x1 | 8.5 | 23.5 | 102 | 9.2 | 2.64 |
HC 215-45 | 2-13/16 | 5.1181 | 3.626 | 2.9528 | 1.1811 | 1.469 | 3/8-24UNF | 0.335 | 0.925 | 4.016 | 0.362 | 2.94 |
HC 215-46 | 7/8 | 5.1181 | 3.626 | 2.9528 | 1.1811 | 1.469 | 3/8-24UNF | 0.335 | 0.925 | 4.016 | 0.362 | 2.81 |
HC 215-47 | 2-15/16 | 5.1181 | 3.626 | 2.9528 | 1.1811 | 1.469 | 3/8-24UNF | 0.335 | 0.925 | 4.016 | 0.362 | 2.54 |
HC 215-48 | 3 | 5.1181 | 3.626 | 2.9528 | 1.1811 | 1.469 | 3/8-24UNF | 0.335 | 0.925 | 4.016 | 0.362 | 2.5 |
HC216 | 80 | 140 | 95.2 | 74.6 | 32 | 37.3 | M12x1.5 | 10.5 | 27 | 110 | 9.5 | 3.33 |
HC 216-49 | 1/16 | 5.5118 | 3.748 | 2.937 | 1.2598 | 1.4685 | 1/2-20UNF | 0.4133 | 1.063 | 4.3307 | 0.374 | 3.53 |
HC 216-50 | 1/8 | 5.5118 | 3.748 | 2.937 | 1.2598 | 1.4685 | 1/2-20UNF | 0.4133 | 1.063 | 4.3307 | 0.374 | 3.39 |
HC 216-51 | 3/16 | 5.5118 | 3.748 | 2.937 | 1.2598 | 1.4685 | 1/2-20UNF | 0.4133 | 1.063 | 4.3307 | 0.374 | 3.24 |
HC217 | 85 | 150 | 73.8 | 53.2 | 34 | 23.4 | M12x1.5 | 10.5 | 27 | 119 | 10.2 | 3.54 |
HC 217-52 | 1/4 | 5.9055 | 2.9055 | 2.0945 | 1.3386 | 0.9213 | 1/2-20UNF | 0.4133 | 1.063 | 4.685 | 0.402 | 3.73 |
HC 217-53 | 5/16 | 5.9055 | 2.9055 | 2.0945 | 1.3386 | 0.9213 | 1/2-20UNF | 0.4133 | 1.063 | 4.685 | 0.402 | 3.61 |
HC 217-55 | 7/16 | 5.9055 | 2.9055 | 2.0945 | 1.3386 | 0.9213 | 1/2-20UNF | 0.4133 | 1.063 | 4.685 | 0.402 | 3.36 |
HC218 | 90 | 160 | 72.6 | 55 | 36 | 24.5 | M12x1.5 | 9 | 24 | 122 | 11.2 | 3.86 |
HC 218-56 | 1/2 | 6.2992 | 2.8583 | 2.1654 | 1.4173 | 0.9645 | 1/2-20UNF | 0.3543 | 0.9449 | 4.8031 | 0.441 | 3.95 |
Bearing NO. | Dimensions(mm/in.) | Weight(kg) | ||||||||||
d | D | B1 | B | C | S | ds | G | B5 | d3 | F | ||
HC305 | 25 | 62 | 46.8 | 34.9 | 20 | 16.7 | M8x1 | 6 | 15.9 | 42.8 | 5.4 | 0.43 |
HC 305-13 | 13/16 | 2.4409 | 1.843 | 1.374 | 0.7874 | 0.657 | 5/16-24UNF | 0.236 | 0.626 | 1.685 | 0.213 | 0.49 |
HC 305-14 | 7/8 | 2.4409 | 1.843 | 1.374 | 0.7874 | 0.657 | 5/16-24UNF | 0.236 | 0.626 | 1.685 | 0.213 | 0.48 |
HC 305-15 | 15/16 | 2.4409 | 1.843 | 1.374 | 0.7874 | 0.657 | 5/16-24UNF | 0.236 | 0.626 | 1.685 | 0.213 | 0.46 |
HC 305-16 | 1 | 2.4409 | 1.843 | 1.374 | 0.7874 | 0.657 | 5/16-24UNF | 0.236 | 0.626 | 1.685 | 0.213 | 0.44 |
HC306 | 30 | 72 | 50 | 36.5 | 23 | 17.5 | M8x1 | 7 | 17.5 | 50 | 5.7 | 0.69 |
HC 306-17 | 1/16 | 2.8346 | 1.969 | 1.437 | 0.9055 | 0.689 | 5/16-24UNF | 0.276 | 0.689 | 1.969 | 0.224 | 0.71 |
HC 306-18 | 1/8 | 2.8346 | 1.969 | 1.437 | 0.9055 | 0.689 | 5/16-24UNF | 0.276 | 0.689 | 1.969 | 0.224 | 0.68 |
HC 306-19 | 3/16 | 2.8346 | 1.969 | 1.437 | 0.9055 | 0.689 | 5/16-24UNF | 0.276 | 0.689 | 1.969 | 0.224 | 0.66 |
HC307 | 35 | 80 | 51.6 | 38.1 | 25 | 18.3 | M8x1 | 7 | 17.5 | 55 | 6.2 | 0.8 |
HC 307-20 | 1/4 | 3.1496 | 2.031 | 1.5 | 0.9843 | 0.72 | 5/16-24UNF | 0.276 | 0.689 | 2.165 | 0.244 | 0.87 |
HC 307-21 | 5/16 | 3.1496 | 2.031 | 1.5 | 0.9843 | 0.72 | 5/16-24UNF | 0.276 | 0.689 | 2.165 | 0.244 | 0.83 |
HC 307-22 | 3/8 | 3.1496 | 2.031 | 1.5 | 0.9843 | 0.72 | 5/16-24UNF | 0.276 | 0.689 | 2.165 | 0.244 | 0.8 |
HC 307-23 | 7/16 | 3.1496 | 2.031 | 1.5 | 0.9843 | 0.72 | 5/16-24UNF | 0.276 | 0.689 | 2.165 | 0.244 | 0.77 |
HC308 | 40 | 90 | 57.1 | 41.3 | 27 | 19.8 | M10x1 | 8 | 20.6 | 63.5 | 7 | 1.08 |
HC 308-24 | 1/2 | 3.5433 | 2.248 | 1.626 | 1.063 | 0.78 | 3/8-24UNF | 0.315 | 0.811 | 2.5 | 0.276 | 1.17 |
HC 308-25 | 9/16 | 3.5433 | 2.248 | 1.626 | 1.063 | 0.78 | 3/8-24UNF | 0.315 | 0.811 | 2.5 | 0.276 | 1.13 |
HC309 | 45 | 100 | 58.7 | 42.9 | 30 | 19.8 | M10x1 | 8 | 20.6 | 70 | 7.8 | 1.46 |
HC 309-26 | 5/8 | 3.937 | 2.311 | 1.689 | 1.1811 | 0.78 | 3/8-24UNF | 0.315 | 0.811 | 2.756 | 0.307 | 1.54 |
HC 309-27 | 11/16 | 3.937 | 2.311 | 1.689 | 1.1811 | 0.78 | 3/8-24UNF | 0.315 | 0.811 | 2.756 | 0.307 | 1.49 |
HC 309-28 | 3/4 | 3.937 | 2.311 | 1.689 | 1.1811 | 0.78 | 3/8-24UNF | 0.315 | 0.811 | 2.756 | 0.307 | 1.44 |
HC310 | 50 | 110 | 66.6 | 49.2 | 32 | 24.6 | M10x1 | 9 | 22.2 | 76.2 | 8.5 | 1.86 |
HC 310-29 | 1-13/16 | 4.3307 | 2.622 | 1.937 | 1.2598 | 0.969 | 3/8-24UNF | 0.354 | 0.874 | 3 | 0.335 | 2 |
HC 310-30 | 7/8 | 4.3307 | 2.622 | 1.937 | 1.2598 | 0.969 | 3/8-24UNF | 0.354 | 0.874 | 3 | 0.335 | 1.95 |
HC 310-31 | 1-15/16 | 4.3307 | 2.622 | 1.937 | 1.2598 | 0.969 | 3/8-24UNF | 0.354 | 0.874 | 3 | 0.335 | 1.88 |
HC311 | 55 | 120 | 73 | 55.6 | 34 | 27.8 | M10x1 | 9 | 22.2 | 83 | 9.2 | 2.34 |
HC 311-32 | 2 | 4.7244 | 2.874 | 2.185 | 1.3386 | 1.094 | 3/8-24UNF | 0.354 | 0.874 | 3.268 | 0.362 | 2.53 |
HC 311-33 | 1/16 | 4.7244 | 2.874 | 2.185 | 1.3386 | 1.094 | 3/8-24UNF | 0.354 | 0.874 | 3.268 | 0.362 | 2.44 |
HC 311-34 | 1/8 | 4.7244 | 2.874 | 2.185 | 1.3386 | 1.094 | 3/8-24UNF | 0.354 | 0.874 | 3.268 | 0.362 | 2.38 |
HC 311-35 | 3/16 | 4.7244 | 2.874 | 2.185 | 1.3386 | 1.094 | 3/8-24UNF | 0.354 | 0.874 | 3.268 | 0.362 | 2.3 |
HC312 | 60 | 130 | 79.4 | 61.9 | 36 | 30.95 | M10x1 | 9 | 23.9 | 89 | 9.8 | 2.94 |
HC 312-36 | 1/4 | 5.1181 | 3.126 | 2.437 | 1.4173 | 1.219 | 3/8-24UNF | 0.354 | 0.941 | 3.504 | 0.386 | 3.08 |
HC 312-37 | 5/16 | 5.1181 | 3.126 | 2.437 | 1.4173 | 1.219 | 3/8-24UNF | 0.354 | 0.941 | 3.504 | 0.386 | 3.02 |
HC 312-38 | 3/8 | 5.1181 | 3.126 | 2.437 | 1.4173 | 1.219 | 3/8-24UNF | 0.354 | 0.941 | 3.504 | 0.386 | 2.94 |
HC 312-39 | 7/16 | 5.1181 | 3.126 | 2.437 | 1.4173 | 1.219 | 3/8-24UNF | 0.354 | 0.941 | 3.504 | 0.386 | 2.81 |
HC313 | 65 | 140 | 85.2 | 64.6 | 38 | 32.55 | M12x1.5 | 10.5 | 27 | 97 | 10.5 | 3.64 |
HC 313-40 | 1/2 | 5.5118 | 3.354 | 2.5433 | 1.4961 | 1.282 | 1/2-20UNF | 0.413 | 1.063 | 3.819 | 0.413 | 3.73 |
HC 313-41 | 9/16 | 5.5118 | 3.354 | 2.5433 | 1.4961 | 1.282 | 1/2-20UNF | 0.413 | 1.063 | 3.819 | 0.413 | 3.72 |
HC314 | 70 | 150 | 92.1 | 68.3 | 40 | 34.15 | M12x1.5 | 12 | 30.2 | 102 | 11.1 | 4.37 |
HC 314-42 | 5/8 | 5.9055 | 3.626 | 2.689 | 1.5748 | 1.344 | 1/2-20UNF | 0.472 | 1.189 | 4.016 | 0.437 | 4.69 |
HC 314-43 | 11/16 | 5.9055 | 3.626 | 2.689 | 1.5748 | 1.344 | 1/2-20UNF | 0.472 | 1.189 | 4.016 | 0.437 | 4.6 |
HC 314-44 | 3/4 | 5.9055 | 3.626 | 2.689 | 1.5748 | 1.344 | 1/2-20UNF | 0.472 | 1.189 | 4.016 | 0.437 | 4.49 |
HC315 | 75 | 160 | 100 | 74.6 | 42 | 37.3 | M16x1.5 | 13 | 31.8 | 113 | 11.8 | 5.3 |
HC 315-45 | 2-13/16 | 6.2992 | 3.937 | 2.937 | 1.6535 | 1.469 | 5/8-18UNF | 0.512 | 1.252 | 4.449 | 0.456 | 5.95 |
HC 315-46 | 7/8 | 6.2992 | 3.937 | 2.937 | 1.6535 | 1.469 | 5/8-18UNF | 0.512 | 1.252 | 4.449 | 0.456 | 5.81 |
HC 315-47 | 2-15/16 | 6.2992 | 3.937 | 2.937 | 1.6535 | 1.469 | 5/8-18UNF | 0.512 | 1.252 | 4.449 | 0.456 | 5.72 |
HC 315-48 | 3 | 6.2992 | 3.937 | 2.937 | 1.6535 | 1.469 | 5/8-18UNF | 0.512 | 1.252 | 4.449 | 0.456 | 5.63 |
HC316 | 80 | 170 | 106.4 | 81 | 44 | 40.5 | M16x1.5 | 13 | 31.8 | 119 | 12.5 | 6.66 |
HC 316-49 | 1/16 | 6.6929 | 4.189 | 3.189 | 1.7323 | 1.594 | 5/8-18UNF | 0.512 | 1.252 | 4.685 | 0.492 | 6.72 |
HC 316-50 | 1/8 | 6.6929 | 4.189 | 3.189 | 1.7323 | 1.594 | 5/8-18UNF | 0.512 | 1.252 | 4.685 | 0.492 | 6.67 |
HC 316-51 | 3/16 | 6.6929 | 4.189 | 3.189 | 1.7323 | 1.594 | 5/8-18UNF | 0.512 | 1.252 | 4.685 | 0.492 | 6.58 |
HC317 | 85 | 180 | 109.5 | 84.1 | 46 | 42.05 | M16x1.5 | 13 | 31.8 | 127 | 13.1 | 7.95 |
HC 317-52 | 1/4 | 7.0866 | 4.311 | 3.311 | 1.811 | 1.656 | 5/8-18UNF | 0.512 | 1.252 | 5 | 0.516 | 8.12 |
HC 317-53 | 5/16 | 7.0866 | 4.311 | 3.311 | 1.811 | 1.656 | 5/8-18UNF | 0.512 | 1.252 | 5 | 0.516 | 7.98 |
HC 317-55 | 7/16 | 7.0866 | 4.311 | 3.311 | 1.811 | 1.656 | 5/8-18UNF | 0.512 | 1.252 | 5 | 0.516 | 7.66 |
HC318 | 90 | 190 | 115.9 | 87.3 | 48 | 43.65 | M20x1.5 | 14.5 | 36.5 | 133 | 13.8 | 9.05 |
HC 318-55 | 7/16 | 7.4803 | 4.563 | 3.437 | 1.8898 | 1.719 | 3/4-16UNF | 0.571 | 1.437 | 5.236 | 0.543 | 9.34 |
HC 318-56 | 1/2 | 7.4803 | 4.563 | 3.437 | 1.8898 | 1.719 | 3/4-16UNF | 0.571 | 1.437 | 5.236 | 0.543 | 9.11 |
HC319 | 95 | 200 | 122.3 | 93.7 | 50 | 38.9 | M20x1.5 | 14.5 | 36.5 | 140 | 14.7 | 10.34 |
HC 319-58 | 5/8 | 7.874 | 4.815 | 3.689 | 1.9685 | 1.531 | 3/4-16UNF | 0.571 | 1.437 | 5.512 | 0.579 | 10.56 |
HC 319-59 | 11/16 | 7.874 | 4.815 | 3.689 | 1.9685 | 1.531 | 3/4-16UNF | 0.571 | 1.437 | 5.512 | 0.579 | 10.38 |
HC 317-60 | 3/4 | 7.874 | 4.815 | 3.689 | 1.9685 | 1.531 | 3/4-16UNF | 0.571 | 1.437 | 5.512 | 0.579 | 10.19 |
HC320 | 100 | 215 | 128.6 | 100 | 54 | 50 | M20x1.5 | 14.5 | 36.5 | 146 | 15.7 | 12.43 |
HC 320-64 | 4 | 8.4646 | 5.063 | 3.937 | 2.126 | 1.969 | 3/4-16UNF | 0.571 | 1.437 | 5.748 | 0.618 | 12.18 |
