Bearing NO. | Dimensions(mm/in.) | Dynamic load ratings(N) | Static load ratings(N) | Weight(kg) | ||
d | D | B | ||||
CS200 | 10 | 30 | 9 | 5100 | 2230 | 0.031 |
CS200 | 0.3937 | 1.1811 | 0.3543 | 5100 | 2230 | 0.031 |
CS201 | 12 | 32 | 10 | 6800 | 3050 | 0.033 |
CS201 | 0.4724 | 1.2598 | 0.3937 | 6800 | 3050 | 0.033 |
CS202 | 15 | 35 | 11 | 7600 | 3490 | 0.043 |
CS202 | 0.5906 | 1.378 | 0.4331 | 7600 | 3490 | 0.043 |
CS203 | 17 | 40 | 12 | 9600 | 4600 | 0.061 |
CS203 | 0.6693 | 1.5748 | 0.4724 | 9600 | 4600 | 0.061 |
CS204 | 20 | 47 | 14 | 12800 | 6600 | 0.098 |
CS204 | 0.7874 | 1.8504 | 0.5512 | 12800 | 6600 | 0.098 |
CS205 | 25 | 52 | 15 | 1400 | 7850 | 0.122 |
CS205 | 0.9843 | 2.0472 | 0.5906 | 1400 | 7850 | 0.122 |
CS206 | 30 | 62 | 16 | 19400 | 11250 | 0.195 |
CS206 | 1.1811 | 2.4409 | 0.6299 | 19400 | 11250 | 0.195 |
CS207 | 35 | 72 | 17 | 25700 | 15300 | 0.28 |
CS207 | 1.378 | 2.8346 | 0.6693 | 25700 | 15300 | 0.28 |
CS208 | 40 | 80 | 18 | 29500 | 18100 | 0.358 |
CS208 | 1.5748 | 3.1496 | 0.7087 | 29500 | 18100 | 0.358 |
CS209 | 45 | 85 | 19 | 32700 | 20900 | 0.405 |
CS209 | 1.7717 | 0.029448819 | 0.748 | 32700 | 20900 | 0.405 |
CS210 | 50 | 90 | 20 | 3500 | 23200 | 0.449 |
CS210 | 1.9685 | 3.5433 | 0.7874 | 3500 | 23200 | 0.449 |
CS211 | 55 | 100 | 21 | 43300 | 29200 | 0.589 |
CS211 | 2.1654 | 3.937 | 0.8268 | 43300 | 29200 | 0.589 |
CS212 | 60 | 110 | 22 | 47700 | 32800 | 0.774 |
CS212 | 2.3622 | 4.3307 | 0.8661 | 47700 | 32800 | 0.774 |
CS302 | 15 | 42 | 13 | 11440 | 5430 | 0.076 |
CS302 | 0.5906 | 1.6535 | 0.5118 | 11440 | 5430 | 0.076 |
CS303 | 17 | 47 | 14 | 13585 | 6560 | 0.105 |
CS303 | 0.6693 | 1.8504 | 0.5512 | 13585 | 6560 | 0.105 |
CS304 | 20 | 52 | 15 | 15938 | 7810 | 0.137 |
CS304 | 0.7874 | 2.0472 | 0.5906 | 15938 | 7810 | 0.137 |
CS305 | 25 | 62 | 17 | 22400 | 11500 | 0.211 |
CS305 | 0.9843 | 2.4409 | 0.6693 | 22400 | 11500 | 0.211 |
CS306 | 30 | 72 | 19 | 26500 | 14900 | 0.338 |
CS306 | 1.1811 | 2.8346 | 0.748 | 26500 | 14900 | 0.338 |
CS307 | 35 | 80 | 21 | 33300 | 19100 | 0.439 |
CS307 | 1.378 | 3.1496 | 0.8268 | 33300 | 19100 | 0.439 |
CS308 | 40 | 90 | 23 | 40600 | 23700 | 0.618 |
CS308 | 1.5748 | 3.5433 | 0.9055 | 40600 | 23700 | 0.618 |
CS309 | 45 | 100 | 25 | 48600 | 28900 | 0.81 |
CS309 | 1.7717 | 3.937 | 0.9843 | 48600 | 28900 | 0.81 |
CS310 | 50 | 110 | 27 | 6200 | 3800 | 1.048 |
CS310 | 1.9685 | 4.3307 | 1.063 | 6200 | 3800 | 1.048 |
CS311 | 55 | 120 | 29 | 71600 | 44600 | 1.326 |
CS311 | 2.1654 | 4.7244 | 1.1417 | 71600 | 44600 | 1.326 |
CS312 | 60 | 130 | 31 | 81600 | 51800 | 1.659 |
CS312 | 2.3622 | 5.1181 | 1.2205 | 81600 | 51800 | 1.659 |
