Bearing No. | Equivalent | Dimensions [mm] | Weight [kg] | Bearing type | ||
d | D | B | ||||
178810. | 234410 | 50 | 80 | 38 | 0,65 | angular-contact double-direction thrust ball bearings |
178811. | 234411 | 55 | 90 | 44 | 0,91 | angular-contact double-direction thrust ball bearings |
178812. | 234412 | 60 | 95 | 44 | 1,06 | angular-contact double-direction thrust ball bearings |
178813. | 234413 | 65 | 100 | 44 | 1,13 | angular-contact double-direction thrust ball bearings |
178814. | 234414 | 70 | 110 | 48 | 1,5 | angular-contact double-direction thrust ball bearings |
178815. | 234415 | 75 | 115 | 48 | 1,62 | angular-contact double-direction thrust ball bearings |
178816. | 234416 | 80 | 125 | 54 | 2,11 | angular-contact double-direction thrust ball bearings |
178817. | 234417 | 85 | 130 | 54 | 2,27 | angular-contact double-direction thrust ball bearings |
178818. | 234418 | 90 | 140 | 60 | 2,82 | angular-contact double-direction thrust ball bearings |
178819. | 234419 | 95 | 145 | 60 | 2,96 | angular-contact double-direction thrust ball bearings |
178820. | 234420 | 100 | 150 | 60 | 3,12 | angular-contact double-direction thrust ball bearings |
178822. | 234422 | 110 | 170 | 72 | 5,12 | angular-contact double-direction thrust ball bearings |
178824. | 234424 | 120 | 180 | 84 | 5,3 | angular-contact double-direction thrust ball bearings |
178826. | 234426 | 130 | 200 | 84 | 8,15 | angular-contact double-direction thrust ball bearings |
178828. | 234428 | 140 | 210 | 84 | 9,23 | angular-contact double-direction thrust ball bearings |
178830. | 234430 | 150 | 225 | 10,6 | angular-contact double-direction thrust ball bearings | |
178832. | 234432 | 160 | 240 | 108 | 12,7 | angular-contact double-direction thrust ball bearings |
178834. | 234434 | 170 | 260 | 120 | 17,8 | angular-contact double-direction thrust ball bearings |
178836. | 234436 | 180 | 280 | 23,1 | angular-contact double-direction thrust ball bearings | |
178840. | 234440 | 200 | 310 | 31 | angular-contact double-direction thrust ball bearings | |
178908. | 234708 | 42 | 68 | 36 | 0,44 | angular-contact double-direction thrust ball bearings |
178916. | 234716 | 84 | 125 | 54 | 1,95 | angular-contact double-direction thrust ball bearings |
178920. | 234720 | 103 | 150 | 60 | 2,9 | angular-contact double-direction thrust ball bearings |
178922. | 234722 | 114 | 170 | 72 | 4,8 | angular-contact double-direction thrust ball bearings |
178928. | 234728 | 145 | 210 | 8,41 | angular-contact double-direction thrust ball bearings | |
1006094. | 4 | 11 | 4 | 0,002 | angular-contact radial ball bearings | |
1006095. | 5 | 13 | 4 | 0,003 | angular-contact radial ball bearings | |
1006096. | 6 | 15 | 5 | 0,004 | angular-contact radial ball bearings | |
1236918. | 90 | 125 | 36 | 1,23 | angular-contact radial ball bearings | |
1246918. | 90 | 125 | 54 | 1,85 | angular-contact radial ball bearings | |
1246922. | 110 | 150 | 40 | 1,68 | angular-contact radial ball bearings | |
1246932. | 160 | 220 | 84 | 8,68 | angular-contact radial ball bearings | |
1246932. | 160 | 220 | 56 | 5,34 | angular-contact radial ball bearings | |
1436900. | 10 | 22 | 12 | 0,021 | angular-contact radial ball bearings | |
1546908. | 40 | 62 | 48 | 0,48 | angular-contact radial ball bearings | |
1846922. | 110 | 150 | 60 | 2,84 | angular-contact radial ball bearings | |
236104. | 7004 C-UO x2 | 20 | 42 | 24 | 0,13 | angular-contact radial ball bearings |
236105. | 7005 C-UO x2 | 25 | 47 | 24 | 0,15 | angular-contact radial ball bearings |
236106. | 7006 C-UO x2 | 30 | 55 | 26 | 0,23 | angular-contact radial ball bearings |
236107. | 7007 C-UO x2 | 35 | 62 | 28 | 0,3 | angular-contact radial ball bearings |
236108. | 7008 C-UO x2 | 40 | 68 | 30 | 0,37 | angular-contact radial ball bearings |
236109. | 7009 C-UO x2 | 45 | 75 | 32 | 0,48 | angular-contact radial ball bearings |
236111. | 7011 C-UO x2 | 55 | 90 | 36 | 0,76 | angular-contact radial ball bearings |
236113. | 7013 C-UO x2 | 65 | 100 | 36 | 0,87 | angular-contact radial ball bearings |
236114. | 7014 C-UO x2 | 70 | 110 | 40 | 1,22 | angular-contact radial ball bearings |
236115. | 7015 C-UO x2 | 75 | 115 | 40 | 1,26 | angular-contact radial ball bearings |
236117. | 7017 C-UO x2 | 85 | 130 | 44 | 1,96 | angular-contact radial ball bearings |
236118. | 7018 C-UO x2 | 90 | 140 | 48 | 2,3 | angular-contact radial ball bearings |
236124. | 7024 C-UO x2 | 120 | 180 | 56 | 4,08 | angular-contact radial ball bearings |
236201. | 7001 C-UO x2 | 12 | 32 | 20 | 0,074 | angular-contact radial ball bearings |
236202. | 7202 C-UO x2 | 15 | 35 | 22 | 0,09 | angular-contact radial ball bearings |
236203. | 7203 C-UO x2 | 17 | 40 | 24 | 0,125 | angular-contact radial ball bearings |
236204. | 7204 C-UO x2 | 20 | 47 | 28 | 0,203 | angular-contact radial ball bearings |
236205. | 7205 C-UO x2 | 25 | 52 | 30 | 0,244 | angular-contact radial ball bearings |
236206. | 7206 C-UO x2 | 30 | 62 | 32 | 0,41 | angular-contact radial ball bearings |
236207. | 7207 C-UO x2 | 35 | 72 | 34 | 0,56 | angular-contact radial ball bearings |
236208. | 7208 C-UO x2 | 40 | 80 | 36 | 0,72 | angular-contact radial ball bearings |
236210. | 7210 C-UO x2 | 50 | 90 | 40 | 0,89 | angular-contact radial ball bearings |
236211. | 7211 C-UO x2 | 55 | 100 | 42 | 1,2 | angular-contact radial ball bearings |
236214. | 7214 C-UO x2 | 70 | 125 | 48 | 2,19 | angular-contact radial ball bearings |
236217. | 7217C-UDx2 | 85 | 150 | 56 | 3,36 | angular-contact radial ball bearings |
236219. | 7219 C-UO x2 | 95 | 170 | 64 | 5,2 | angular-contact radial ball bearings |
246108. | 7008 A-UO x2 | 40 | 68 | 30 | 0,39 | angular-contact radial ball bearings |
246109. | 7009 A-UO x2 | 45 | 75 | 32 | 0,5 | angular-contact radial ball bearings |
246110. | 7010 A-UO x2 | 50 | 80 | 36 | 0,54 | angular-contact radial ball bearings |
246111. | 7011 A x3 | 55 | 90 | 54 | 1,25 | angular-contact radial ball bearings |
246111. | 7011 A-UO x2 | 55 | 90 | 36 | 0,83 | angular-contact radial ball bearings |
246112. | 7012 A-UO x2 | 60 | 95 | 36 | 0,84 | angular-contact radial ball bearings |
246112. | 7013 Ax3 | 60 | 95 | 54 | 1,26 | angular-contact radial ball bearings |
246113. | 7014 A x3 | 65 | 100 | 54 | 1,44 | angular-contact radial ball bearings |
246116. | 7016 Ax3 | 80 | 125 | 66 | 2,5 | angular-contact radial ball bearings |
246117. | 7017 A-UO x2 | 85 | 130 | 44 | 1,96 | angular-contact radial ball bearings |
24612. | 7016 A-UO x2 | 130 | 200 | 66 | 7,4 | angular-contact radial ball bearings |
24612. | 7020 A-UO x2 | 100 | 150 | 48 | 2,92 | angular-contact radial ball bearings |
246120. | 7020 A x3 | 100 | 150 | 72 | 4,38 | angular-contact radial ball bearings |
246126. | 7026 A x3 | 130 | 200 | 99 | 9,75 | angular-contact radial ball bearings |
246204. | 7204 A-UO x2 | 20 | 47 | 28 | 0,22 | angular-contact radial ball bearings |
246207. | 7207 A-UO x2 | 35 | 72 | 34 | 0,59 | angular-contact radial ball bearings |
246213. | 7213 A-UO x2 | 65 | 120 | 46 | 2 | angular-contact radial ball bearings |
246222. | 7222 A-UO x2 | 110 | 200 | 76 | 9,6 | angular-contact radial ball bearings |
26202. | 15 | 35 | 11,5 | 0,046 | angular-contact radial ball bearings | |
26216. | 80 | 140 | 26,5 | 1,3 | angular-contact radial ball bearings | |
266130. | 150 | 225 | 70 | 9,86 | angular-contact radial ball bearings | |
266132. | 160 | 240 | 76 | 12,3 | angular-contact radial ball bearings | |
266134. | 170 | 260 | 84 | 16,5 | angular-contact radial ball bearings | |
266140. | 200 | 310 | 102 | 29,6 | angular-contact radial ball bearings | |
266144. | 220 | 340 | 112 | 37,4 | angular-contact radial ball bearings | |
266148. | 240 | 360 | 112 | 40,7 | angular-contact radial ball bearings | |
266152. | 260 | 400 | 130 | 60,6 | angular-contact radial ball bearings | |
266156. | 280 | 420 | 130 | 65 | angular-contact radial ball bearings | |
266206. | 30 | 62 | 32 | 0,42 | angular-contact radial ball bearings | |
266210. | 50 | 90 | 40 | 0,98 | angular-contact radial ball bearings | |
266318. | 90 | 180 | 86 | 10,1 | angular-contact radial ball bearings | |
266340. | 200 | 420 | 160 | 114 | angular-contact radial ball bearings | |
336104. | 20 | 42 | 24 | 0,16 | angular-contact radial ball bearings | |
336106. | 30 | 55 | 26 | 0,23 | angular-contact radial ball bearings | |
336122. | 110 | 170 | 56 | 3,9 | angular-contact radial ball bearings | |
336317. | 85 | 180 | 82 | 9 | angular-contact radial ball bearings | |
336320. | 100 | 215 | 94 | 14,1 | angular-contact radial ball bearings | |
346205. | 7205 C-UX x2 | 25 | 52 | 30 | 0,28 | angular-contact radial ball bearings |
346206. | 7206 A-UX x2 | 30 | 62 | 32 | 0,38 | angular-contact radial ball bearings |
346209. | 7209 A-UX x2 | 45 | 85 | 38 | 0,84 | angular-contact radial ball bearings |
346234. | 7234 A-UX x2 | 170 | 310 | 104 | 33 | angular-contact radial ball bearings |
346308. | 7208 A-UX x2 | 40 | 90 | 46 | 1,26 | angular-contact radial ball bearings |
346310. | 7310 A-UX x2 | 50 | 110 | 54 | 2,2 | angular-contact radial ball bearings |
346312. | 7312 A-UX x2 | 60 | 130 | 62 | 3,52 | angular-contact radial ball bearings |
346313. | 7313 A-UX x2 | 65 | 140 | 66 | 4,18 | angular-contact radial ball bearings |
346317. | 85 | 180 | 82 | 8,59 | angular-contact radial ball bearings | |
346320. | 100 | 215 | 94 | 16,28 | angular-contact radial ball bearings | |
346330. | 150 | 320 | 130 | 54,8 | angular-contact radial ball bearings | |
36100. | 7000 C | 10 | 26 | 8 | 0,039 | angular-contact radial ball bearings |
36101. | 7001 C | 12 | 28 | 8 | 0,021 | angular-contact radial ball bearings |
36102. | 7002 C | 15 | 32 | 9 | 0,033 | angular-contact radial ball bearings |
36103. | 7003 C | 17 | 35 | 10 | 0,04 | angular-contact radial ball bearings |
36104. | 7004 C | 20 | 42 | 12 | 0,068 | angular-contact radial ball bearings |
36105. | 7005 C | 25 | 47 | 12 | 0,122 | angular-contact radial ball bearings |
36106. | 7006 C | 30 | 55 | 13 | 0,195 | angular-contact radial ball bearings |
36107. | 7007 C | 35 | 62 | 14 | 0,25 | angular-contact radial ball bearings |
36108. | 7008 C | 40 | 68 | 15 | 0,195 | angular-contact radial ball bearings |
36109. | 7009 C | 45 | 75 | 16 | 0,25 | angular-contact radial ball bearings |
36110. | 7010 C | 50 | 80 | 16 | 0,27 | angular-contact radial ball bearings |
36111. | 7011 C | 55 | 90 | 18 | 0,39 | angular-contact radial ball bearings |
36112. | 7012 C | 60 | 95 | 18 | 0,42 | angular-contact radial ball bearings |
36113. | 7013 C | 65 | 100 | 18 | 0,45 | angular-contact radial ball bearings |
36114. | 7014 C | 70 | 110 | 20 | 0,62 | angular-contact radial ball bearings |
36115. | 7015 C | 75 | 115 | 20 | 0,65 | angular-contact radial ball bearings |
36116. | 7016 C | 80 | 125 | 22 | 0,87 | angular-contact radial ball bearings |
36117. | 7017 C | 85 | 130 | 22 | 0,91 | angular-contact radial ball bearings |
36118. | 7018 C | 90 | 140 | 24 | 1,19 | angular-contact radial ball bearings |
36120. | 7020 C | 100 | 150 | 24 | 1,29 | angular-contact radial ball bearings |
36121. | 7021 C | 105 | 160 | 26 | 1,58 | angular-contact radial ball bearings |
36201. | 7201 C | 12 | 32 | 10 | 0,01 | angular-contact radial ball bearings |
36202. | 7202 C | 15 | 35 | 11 | 0,04 | angular-contact radial ball bearings |
36203. | 7203 C | 17 | 40 | 12 | 0,06 | angular-contact radial ball bearings |
36204. | 7204 C | 20 | 47 | 14 | 0,09 | angular-contact radial ball bearings |
36205. | 7205 C | 25 | 52 | 15 | 0,122 | angular-contact radial ball bearings |
36206. | 7206 C | 30 | 62 | 16 | 0,19 | angular-contact radial ball bearings |
36207. | 7207 C | 35 | 72 | 17 | 0,27 | angular-contact radial ball bearings |
36208. | 7208 C | 40 | 80 | 18 | 0,37 | angular-contact radial ball bearings |
36209. | 7209 C | 45 | 85 | 19 | 0,42 | angular-contact radial ball bearings |
36210. | 7210 C | 50 | 90 | 20 | 0,47 | angular-contact radial ball bearings |
36212. | 7212 C | 60 | 110 | 22 | 0,77 | angular-contact radial ball bearings |
36214. | 7214 C | 70 | 125 | 24 | 1,1 | angular-contact radial ball bearings |
36216. | 7216 C | 80 | 140 | 26 | 1,44 | angular-contact radial ball bearings |
36217. | 7217 C | 85 | 150 | 28 | 1,8 | angular-contact radial ball bearings |
36218. | 7218 C | 90 | 160 | 30 | 2,2 | angular-contact radial ball bearings |
36219. | 7219 C | 95 | 170 | 32 | 2,63 | angular-contact radial ball bearings |
36220. | 7220 C | 100 | 180 | 34 | 3,28 | angular-contact radial ball bearings |
36300. | 7300 C | 10 | 35 | 11 | 0,052 | angular-contact radial ball bearings |
36302. | 7302 C | 15 | 42 | 13 | 0,09 | angular-contact radial ball bearings |
36303. | 7303 C | 17 | 47 | 14 | 0,11 | angular-contact radial ball bearings |
36308. | 7308 C | 40 | 90 | 23 | 0,63 | angular-contact radial ball bearings |
36318. | 7318 C | 90 | 190 | 43 | 5 | angular-contact radial ball bearings |
366156. | 280 | 420 | 130 | 64,2 | angular-contact radial ball bearings | |
366203. | 17 | 40 | 24 | 0,14 | angular-contact radial ball bearings | |
366210. | 7210 B-UX x2 | 50 | 90 | 40 | 0,97 | angular-contact radial ball bearings |
366222. | 7322 B-UX x2 | 110 | 240 | 100 | 22,3 | angular-contact radial ball bearings |
366318. | 7318 B-UX x2 | 90 | 190 | 86 | 5,34 | angular-contact radial ball bearings |
366326. | 7326 B-UX x2 | 130 | 280 | 108 | 36,7 | angular-contact radial ball bearings |
366340. | 200 | 420 | 160 | 114 | angular-contact radial ball bearings | |
366408. | 40 | 110 | 54 | 2,74 | angular-contact radial ball bearings | |
366412. | 60 | 150 | 70 | 7,04 | angular-contact radial ball bearings | |
436101. | 7001 C-UD x2 | 12 | 28 | 16 | 0,045 | angular-contact radial ball bearings |
436105. | 7005 C-UD x2 | 25 | 47 | 24 | 0,16 | angular-contact radial ball bearings |
436106. | 7006 C-UD x2 | 30 | 55 | 26 | 0,23 | angular-contact radial ball bearings |
436107. | 7007 C-UD x2 | 35 | 62 | 28 | 0,3 | angular-contact radial ball bearings |
436110. | 7210 C-UD x2 | 50 | 80 | 32 | 0,52 | angular-contact radial ball bearings |
436111. | 7011 C-UDx2 | 55 | 90 | 36 | 0,76 | angular-contact radial ball bearings |
436112. | 7012 C-UD x2 | 60 | 95 | 36 | 0,81 | angular-contact radial ball bearings |
436113. | 7013 C-UD x2 | 65 | 100 | 36 | 0,87 | angular-contact radial ball bearings |
436114. | 7014 C-UD x2 | 70 | 110 | 40 | 1,2 | angular-contact radial ball bearings |
436116. | 7016 C-UD x2 | 80 | 125 | 44 | 1,68 | angular-contact radial ball bearings |
436117. | 7017 C-UD x2 | 85 | 130 | 44 | 1,76 | angular-contact radial ball bearings |
436118. | 7018 C-UD x2 | 90 | 140 | 48 | 2,28 | angular-contact radial ball bearings |
436126. | 7026 C-UD x2 | 130 | 200 | 66 | 6,5 | angular-contact radial ball bearings |
436201. | 7201 C-UD x2 | 12 | 32 | 20 | 0,08 | angular-contact radial ball bearings |
436203. | 7203 C-UD x2 | 17 | 40 | 24 | 0,125 | angular-contact radial ball bearings |
436204. | 7204 C-UD x2 | 20 | 47 | 28 | 0,2 | angular-contact radial ball bearings |
436205. | 7205 C-UD x2 | 25 | 52 | 30 | 0,244 | angular-contact radial ball bearings |
436206. | 7206 C-UD x2 | 30 | 62 | 32 | 0,39 | angular-contact radial ball bearings |
436207. | 7207 C-UD x2 | 35 | 72 | 34 | 0,57 | angular-contact radial ball bearings |
436208. | 7208 C-UD x2 | 40 | 80 | 36 | 0,74 | angular-contact radial ball bearings |
436209. | 7209 C-UD x2 | 45 | 85 | 38 | 0,84 | angular-contact radial ball bearings |
436210. | 7210 C-UD x2 | 50 | 90 | 40 | 0,94 | angular-contact radial ball bearings |
436211. | 7211 C-UDx2 | 55 | 100 | 42 | 1,2 | angular-contact radial ball bearings |
436212. | 7212 C-UD x2 | 60 | 110 | 44 | 1,54 | angular-contact radial ball bearings |
436213. | 7213 C-UD x2 | 65 | 120 | 46 | 1,96 | angular-contact radial ball bearings |
436214. | 7214 C-UD x2 | 70 | 125 | 48 | 2,14 | angular-contact radial ball bearings |
436215. | 7215 C-UD x2 | 75 | 130 | 50 | 2,78 | angular-contact radial ball bearings |
446202. | 7202A-UDx2 | 15 | 35 | 22 | 0,09 | angular-contact radial ball bearings |
446206. | 7206A-UDx2 | 30 | 62 | 32 | 0,46 | angular-contact radial ball bearings |
446207. | 7207A-UDx2 | 35 | 72 | 34 | 0,57 | angular-contact radial ball bearings |
446208. | 7208A-UDx2 | 40 | 80 | 36 | 0,74 | angular-contact radial ball bearings |
446209. | 7209A-UDx2 | 45 | 85 | 38 | 0,84 | angular-contact radial ball bearings |
446210. | 7210A-UDx2 | 50 | 90 | 40 | 0,94 | angular-contact radial ball bearings |
446211. | 7211 A-UDx2 | 55 | 100 | 42 | 1,2 | angular-contact radial ball bearings |
446212. | 7212A-UDx2 | 60 | 110 | 44 | 1,52 | angular-contact radial ball bearings |
446213. | 7213A-UDx2 | 65 | 120 | 46 | 1,98 | angular-contact radial ball bearings |
446215. | 7215A-UDx2 | 75 | 130 | 50 | 2,56 | angular-contact radial ball bearings |
446216. | 7216A-UDx2 | 80 | 140 | 52 | 3,36 | angular-contact radial ball bearings |
446220. | 7220A-UDx2 | 100 | 180 | 68 | 6,55 | angular-contact radial ball bearings |
446305. | 7305A-UDx2 | 25 | 62 | 34 | 0,57 | angular-contact radial ball bearings |
446306. | 7306A-UDx2 | 30 | 72 | 38 | 0,8 | angular-contact radial ball bearings |
446307. | 7307A-UDx2 | 35 | 80 | 42 | 0,93 | angular-contact radial ball bearings |
446308. | 7308A-UDx2 | 40 | 90 | 46 | 1,26 | angular-contact radial ball bearings |
446311. | 7311 A-UDx2 | 55 | 120 | 58 | 2,84 | angular-contact radial ball bearings |
446312. | 7312A-UDx2 | 60 | 130 | 62 | 3,52 | angular-contact radial ball bearings |
446318. | 7318A-UDx2 | 90 | 190 | 86 | 10 | angular-contact radial ball bearings |
446330. | 150 | 320 | 130 | 54,8 | angular-contact radial ball bearings | |
46106. | 7006 A | 30 | 55 | 13 | 0,18 | angular-contact radial ball bearings |
46107. | 7007 A | 35 | 62 | 14 | 0,16 | angular-contact radial ball bearings |
46108. | 7008 A | 40 | 68 | 15 | 0,22 | angular-contact radial ball bearings |
46109. | 7009 A | 45 | 75 | 16 | 0,24 | angular-contact radial ball bearings |
46110. | 7010A | 50 | 80 | 16 | 0,27 | angular-contact radial ball bearings |
46111. | 7011 A | 55 | 90 | 18 | 0,44 | angular-contact radial ball bearings |
46112. | 7012A | 60 | 95 | 18 | 0,47 | angular-contact radial ball bearings |
46113. | 7013A | 65 | 100 | 18 | 0,45 | angular-contact radial ball bearings |
46114. | 7014 A | 70 | 110 | 20 | 0,72 | angular-contact radial ball bearings |
46115. | 7015A | 75 | 115 | 20 | 0,77 | angular-contact radial ball bearings |
46116. | 7016A | 80 | 125 | 22 | 1 | angular-contact radial ball bearings |
46117. | 7017A | 85 | 130 | 22 | 1,04 | angular-contact radial ball bearings |
46118. | 7018A | 90 | 140 | 24 | 1,19 | angular-contact radial ball bearings |
46120. | 7020 A | 100 | 150 | 24 | 1,56 | angular-contact radial ball bearings |
46121. | 7021 A | 105 | 160 | 26 | 1,85 | angular-contact radial ball bearings |
46122. | 7022 A | 110 | 170 | 28 | 2,41 | angular-contact radial ball bearings |
46202. | 7202 A | 15 | 35 | 11 | 0,045 | angular-contact radial ball bearings |
46203. | 7203 A | 17 | 40 | 12 | 0,063 | angular-contact radial ball bearings |
46204. | 7204 A | 20 | 47 | 14 | 0,1 | angular-contact radial ball bearings |
46205. | 7205 A | 25 | 52 | 15 | 0,144 | angular-contact radial ball bearings |
46206. | 7206 A | 30 | 62 | 16 | 0,232 | angular-contact radial ball bearings |
46207. | 7207 A | 35 | 72 | 17 | 0,289 | angular-contact radial ball bearings |
46208. | 7208 A | 40 | 80 | 18 | 0,37 | angular-contact radial ball bearings |
46209. | 7209 A | 45 | 85 | 19 | 0,4 | angular-contact radial ball bearings |
46210. | 7210A | 50 | 90 | 20 | 0,46 | angular-contact radial ball bearings |
46211. | 7211 A | 55 | 100 | 21 | 0,59 | angular-contact radial ball bearings |
46212. | 7212A | 60 | 110 | 22 | 0,93 | angular-contact radial ball bearings |
46213. | 7213A | 65 | 120 | 23 | 1 | angular-contact radial ball bearings |
46215. | 7215 C | 75 | 130 | 25 | 1,28 | angular-contact radial ball bearings |
46216. | 7215A | 80 | 140 | 26 | 1,68 | angular-contact radial ball bearings |
46217. | 7217A | 85 | 150 | 28 | 1,82 | angular-contact radial ball bearings |
46218. | 7218A | 90 | 160 | 30 | 2,22 | angular-contact radial ball bearings |
46220. | 7220 A | 100 | 180 | 34 | 3,88 | angular-contact radial ball bearings |
46222. | 7222 A | 110 | 200 | 38 | 5,5 | angular-contact radial ball bearings |
462222. | 7222 A-UX x2 | 110 | 240 | 76 | 11 | angular-contact radial ball bearings |
46303. | 7303 A | 17 | 47 | 14 | 0,11 | angular-contact radial ball bearings |
46304. | 7304 A | 20 | 52 | 15 | 0,17 | angular-contact radial ball bearings |
46305. | 7305 A | 25 | 62 | 17 | 0,23 | angular-contact radial ball bearings |
46306. | 7306 A | 30 | 72 | 19 | 0,402 | angular-contact radial ball bearings |
46307. | 7307 A | 35 | 80 | 21 | 0,542 | angular-contact radial ball bearings |
46308. | 7308 A | 40 | 90 | 23 | 0,747 | angular-contact radial ball bearings |
46309. | 7309 A | 45 | 100 | 25 | 0,86 | angular-contact radial ball bearings |
46310. | 7310A | 50 | 110 | 27 | 1,32 | angular-contact radial ball bearings |
46311. | 7311 A | 55 | 120 | 29 | 1,45 | angular-contact radial ball bearings |
46312. | 7312A | 60 | 130 | 31 | 1,71 | angular-contact radial ball bearings |
46313. | 7313A | 65 | 140 | 33 | 2,65 | angular-contact radial ball bearings |
46314. | 7314 A | 70 | 150 | 35 | 3,3 | angular-contact radial ball bearings |
46316. | 7316A | 80 | 170 | 39 | 4,26 | angular-contact radial ball bearings |
46318. | 7318A | 90 | 190 | 43 | 5 | angular-contact radial ball bearings |
46320. | 7320 A | 100 | 215 | 47 | 8,14 | angular-contact radial ball bearings |
46416. | 7416 A | 80 | 200 | 48 | 7,25 | angular-contact radial ball bearings |
46418. | 7418 A | 90 | 225 | 54 | 12 | angular-contact radial ball bearings |
466130. | 150 | 225 | 70 | 9,8 | angular-contact radial ball bearings | |
466203. | 7203 B-UD x2 | 17 | 40 | 24 | 0,14 | angular-contact radial ball bearings |
466230. | 150 | 270 | 90 | 28,4 | angular-contact radial ball bearings | |
466305. | 7305 B-UD x2 | 25 | 62 | 34 | 0,5 | angular-contact radial ball bearings |
466307. | 7307 B-UD x2 | 35 | 80 | 42 | 0,97 | angular-contact radial ball bearings |
466309. | 7309 B-UD x2 | 45 | 100 | 50 | 1,79 | angular-contact radial ball bearings |
466311. | 7311 B-UDx2 | 55 | 120 | 58 | 3 | angular-contact radial ball bearings |
466315. | 7315 B-UD x2 | 75 | 160 | 74 | 7,1 | angular-contact radial ball bearings |
466322. | 7322 B-UD x2 | 110 | 240 | 100 | 22,3 | angular-contact radial ball bearings |
466330. | 7330 B-UD x2 | 150 | 320 | 130 | 48,2 | angular-contact radial ball bearings |
466409. | 45 | 120 | 58 | 3,5 | angular-contact radial ball bearings | |
466412. | 60 | 150 | 70 | 7 | angular-contact radial ball bearings | |
466432. | 160 | 400 | 176 | 124 | angular-contact radial ball bearings | |
576201. | 12 | 32 | 20 | 0,073 | angular-contact radial ball bearings | |
576205. | 25 | 52 | 30 | 0,25 | angular-contact radial ball bearings | |
6003. | 3 | 16 | 5 | 0,006 | angular-contact radial ball bearings | |
6004. | 4 | 16 | 5 | 0,005 | angular-contact radial ball bearings | |
6006. | 6 | 21 | 7 | 0,011 | angular-contact radial ball bearings | |
6008. | 8 | 24 | 7 | 0,015 | angular-contact radial ball bearings | |
6010. | 10 | 28 | 8 | 0,023 | angular-contact radial ball bearings | |
6012. | 12 | 32 | 7 | 0,029 | angular-contact radial ball bearings | |
6015. | 15 | 35 | 8 | 0,035 | angular-contact radial ball bearings | |
6017. | 7 | 19 | 6 | 0,007 | angular-contact radial ball bearings | |
6020. | 20 | 47 | 12 | 0,095 | angular-contact radial ball bearings | |
6023. | 3 | 10 | 4 | 0,002 | angular-contact radial ball bearings | |
6025. | 5 | 16 | 5 | 0,005 | angular-contact radial ball bearings | |
6026. | 6 | 19 | 6 | 0,007 | angular-contact radial ball bearings | |
6027. | 7 | 22 | 7 | 0,011 | angular-contact radial ball bearings | |
6028. | 8 | 24 | 8 | 0,016 | angular-contact radial ball bearings | |
6101. | 12 | 28 | 8 | 0,021 | angular-contact radial ball bearings | |
6102. | 15 | 32 | 9 | 0,029 | angular-contact radial ball bearings | |
6204. | 20 | 47 | 14 | 0,104 | angular-contact radial ball bearings | |
656312. | 60 | 130 | 93 | 5,15 | angular-contact radial ball bearings | |
656322. | 110 | 240 | 150 | 33,5 | angular-contact radial ball bearings | |
656340. | 200 | 420 | 240 | 171 | angular-contact radial ball bearings | |
656412. | 60 | 150 | 105 | 10,1 | angular-contact radial ball bearings | |
656432. | 160 | 400 | 264 | 186 | angular-contact radial ball bearings | |
66202. | 7202 B | 15 | 35 | 11 | 0,05 | angular-contact radial ball bearings |
66203. | 7203 B | 17 | 40 | 12 | 0,07 | angular-contact radial ball bearings |
66204. | 7204 B | 20 | 47 | 14 | 0,11 | angular-contact radial ball bearings |
66205. | 7205 B | 25 | 52 | 15 | 0,13 | angular-contact radial ball bearings |
66207. | 7207 B | 35 | 72 | 17 | 0,29 | angular-contact radial ball bearings |
66208. | 7208 B | 40 | 80 | 18 | 0,39 | angular-contact radial ball bearings |
66209. | 7209 B | 45 | 85 | 19 | 0,44 | angular-contact radial ball bearings |
66210. | 7210 B | 50 | 90 | 20 | 0,49 | angular-contact radial ball bearings |
66211. | 7211 B | 55 | 100 | 21 | 0,75 | angular-contact radial ball bearings |
66211. | 7221 B | 105 | 190 | 36 | 5,16 | angular-contact radial ball bearings |
66212. | 7212 B | 60 | 110 | 22 | 0,87 | angular-contact radial ball bearings |
66215. | 7215 B | 75 | 130 | 25 | 1,42 | angular-contact radial ball bearings |
66217. | 7217 B | 85 | 150 | 28 | 2,08 | angular-contact radial ball bearings |
66218. | 7218 B | 90 | 160 | 30 | 2,44 | angular-contact radial ball bearings |
66219. | 7219 B | 95 | 170 | 32 | 3,18 | angular-contact radial ball bearings |
66220. | 7220 B | 100 | 180 | 34 | 3,55 | angular-contact radial ball bearings |
66303. | 7303 B | 17 | 47 | 14 | 0,15 | angular-contact radial ball bearings |
66307. | 7307 B | 35 | 80 | 21 | 0,51 | angular-contact radial ball bearings |
66308. | 7308 B | 40 | 90 | 23 | 0,695 | angular-contact radial ball bearings |
66309. | 7309 B | 45 | 100 | 25 | 0,87 | angular-contact radial ball bearings |
66311. | 7311 B | 55 | 120 | 29 | 1,55 | angular-contact radial ball bearings |
66312. | 7312 B | 60 | 130 | 31 | 1,71 | angular-contact radial ball bearings |
66314. | 7314 B | 70 | 150 | 35 | 3,1 | angular-contact radial ball bearings |
66315. | 7315 B | 75 | 160 | 37 | 3,3 | angular-contact radial ball bearings |
66319. | 7319 B | 95 | 200 | 45 | 6,25 | angular-contact radial ball bearings |
66322. | 7322 B | 110 | 240 | 50 | 11,16 | angular-contact radial ball bearings |
66406. | 7306 B | 30 | 90 | 23 | 0,77 | angular-contact radial ball bearings |
66408. | 7408 B | 40 | 110 | 27 | 1,37 | angular-contact radial ball bearings |
66409. | 7409 B | 45 | 120 | 29 | 1,75 | angular-contact radial ball bearings |
66410. | 7410 B | 50 | 130 | 31 | 2,17 | angular-contact radial ball bearings |
66412. | 7412 B | 60 | 150 | 35 | 3,87 | angular-contact radial ball bearings |
66414. | 7414 B | 70 | 180 | 42 | 5,74 | angular-contact radial ball bearings |
66418. | 7418 B | 90 | 225 | 54 | 12 | angular-contact radial ball bearings |
666311. | 55 | 120 | 87 | 4,36 | angular-contact radial ball bearings | |
666322. | 110 | 240 | 150 | 33,5 | angular-contact radial ball bearings | |
666432. | 160 | 400 | 264 | 186 | angular-contact radial ball bearings | |
6703. | 17 | 44 | 10 | 0,075 | angular-contact radial ball bearings | |
836108. | 40 | 68 | 45 | 0,58 | angular-contact radial ball bearings | |
836113. | 65 | 100 | 54 | 1,22 | angular-contact radial ball bearings | |
836115. | 75 | 115 | 60 | 1,99 | angular-contact radial ball bearings | |
836126. | 130 | 200 | 99 | 9,84 | angular-contact radial ball bearings | |
836204. | 20 | 47 | 42 | 0,33 | angular-contact radial ball bearings | |
836216. | 80 | 140 | 78 | 4,25 | angular-contact radial ball bearings | |
846109. | 45 | 75 | 48 | 0,78 | angular-contact radial ball bearings | |
846115. | 75 | 115 | 60 | 1,97 | angular-contact radial ball bearings | |
846118. | 90 | 140 | 72 | 3,93 | angular-contact radial ball bearings | |
846122. | 110 | 170 | 84 | 6,42 | angular-contact radial ball bearings | |
846124. | 120 | 180 | 84 | 6,16 | angular-contact radial ball bearings | |
166805. | 25 | 62 | 28 | 0,54 | double-row angular-contact ball bearings | |
256500. | 10 | 30 | 14 | 0,05 | double-row angular-contact ball bearings | |
256705. | 25 | 62 | 28 | 0,29 | double-row angular-contact ball bearings | |
256708. | 42 | 75 | 37 | 0,57 | double-row angular-contact ball bearings | |
256805. | 25 | 52 | 23 | 0,19 | double-row angular-contact ball bearings | |
286805. | 25 | 62 | 28 | 0,52 | double-row angular-contact ball bearings | |
3056203. | 3203 | 17 | 40 | 17,5 | 0,1 | double-row angular-contact ball bearings |
3056204. | 3204 | 20 | 47 | 20,6 | 0,17 | double-row angular-contact ball bearings |
3056205. | 3205 | 25 | 52 | 20,6 | 0,19 | double-row angular-contact ball bearings |
3056206. | 3206 | 30 | 62 | 23,8 | 0,32 | double-row angular-contact ball bearings |
3056207. | 3207 | 35 | 72 | 27 | 0,48 | double-row angular-contact ball bearings |
3056208. | 3208 | 40 | 80 | 30,2 | 0,65 | double-row angular-contact ball bearings |
3056209. | 3209 | 45 | 85 | 30,2 | 0,72 | double-row angular-contact ball bearings |
3056210. | 3210 | 50 | 90 | 30,2 | 0,75 | double-row angular-contact ball bearings |
3056211. | 3211 | 55 | 100 | 33,3 | 1,12 | double-row angular-contact ball bearings |
3056212. | 3212 | 30 | 110 | 36,5 | 1,4 | double-row angular-contact ball bearings |
3056213. | 3213 | 65 | 120 | 38,1 | 1,75 | double-row angular-contact ball bearings |
3056214. | 3214 | 70 | 125 | 39,7 | 1,85 | double-row angular-contact ball bearings |
3056215. | 3215 | 75 | 130 | 41,3 | 2,03 | double-row angular-contact ball bearings |
3056216. | 3216 | 80 | 140 | 44,5 | 2,57 | double-row angular-contact ball bearings |
3056217. | 3217 | 85 | 150 | 49,2 | 3,4 | double-row angular-contact ball bearings |
3056218. | 3218 | 90 | 160 | 52,4 | 4,22 | double-row angular-contact ball bearings |
3056219. | 3219 | 95 | 170 | 55,6 | 5 | double-row angular-contact ball bearings |
3056220. | 3220 | 100 | 180 | 60,3 | 6,14 | double-row angular-contact ball bearings |
3056221. | 3221 | 105 | 190 | 65,1 | 7,14 | double-row angular-contact ball bearings |
3056222. | 3222 | 110 | 200 | 69,8 | 8,8 | double-row angular-contact ball bearings |
3056305. | 3305 | 25 | 62 | 25,4 | 0,37 | double-row angular-contact ball bearings |
3056306. | 3306 | 30 | 72 | 30,2 | 0,59 | double-row angular-contact ball bearings |
3056309. | 3309 | 45 | 100 | 39,7 | 1,4 | double-row angular-contact ball bearings |
3056310. | 3310 | 50 | 110 | 44,4 | 1,95 | double-row angular-contact ball bearings |
3086304. | 20 | 52 | 22,2 | 0,28 | double-row angular-contact ball bearings | |
3086309. | 45 | 100 | 39,7 | 1,42 | double-row angular-contact ball bearings | |
3086313. | 65 | 140 | 58,7 | 3,99 | double-row angular-contact ball bearings | |
3156211. | 55 | 100 | 33,3 | 1,08 | double-row angular-contact ball bearings | |
3156307. | 35 | 80 | 34,9 | 0,94 | double-row angular-contact ball bearings | |
3156896. | 480 | 600 | 90 | 60,2 | double-row angular-contact ball bearings | |
3286208. | 40 | 80 | 30,2 | 0,66 | double-row angular-contact ball bearings | |
3286308. | 40 | 90 | 36,5 | 1,15 | double-row angular-contact ball bearings | |
3286312. | 60 | 130 | 54 | 3,5 | double-row angular-contact ball bearings | |
3286844. | 220 | 270 | 37 | 4,65 | double-row angular-contact ball bearings | |
3286848. | 240 | 300 | 45 | 7,3 | double-row angular-contact ball bearings | |
3756205. | 25 | 52 | 20,6 | 0,2 | double-row angular-contact ball bearings | |
3756206. | 30 | 62 | 23,8 | 0,32 | double-row angular-contact ball bearings | |
50705. | 25 | 57 | 23,8 | 0,28 | double-row angular-contact ball bearings | |
66118. | 90 | 140 | 37 | 2,28 | double-row angular-contact ball bearings | |
776700. | 10 | 41 | 22,4 | 0,14 | double-row angular-contact ball bearings | |
776701. | 12 | 49,4 | 36 | 0,34 | double-row angular-contact ball bearings | |
776702. | 12,7 | 57,5 | 36,5 | 0,39 | double-row angular-contact ball bearings | |
776800. | 10 | 35,85 | 17,7 | 0,14 | double-row angular-contact ball bearings | |
776801. | 12,7 | 51,6 | 24 | 0,34 | double-row angular-contact ball bearings | |
776900. | 11,6 | 39 | 20,76 | 0,15 | double-row angular-contact ball bearings | |
168118. | 90 | 120 | 1 | single-direction angular-contact thrust ball bearings | ||
168124. | 120 | 155 | 72 | 1,11 | single-direction angular-contact thrust ball bearings | |
168130. | 150 | 190 | 90 | 1,9 | single-direction angular-contact thrust ball bearings | |
168132. | 160 | 200 | 96 | 2,06 | single-direction angular-contact thrust ball bearings | |
168140. | 200 | 250 | 132 | 4,05 | single-direction angular-contact thrust ball bearings | |
168148. | 240 | 300 | 6,7 | single-direction angular-contact thrust ball bearings | ||
168160. | 300 | 380 | 15,5 | single-direction angular-contact thrust ball bearings | ||
1687/1060. | 1060 | 1280 | 338 | single-direction angular-contact thrust ball bearings | ||
1688/1060. | 1060 | 1180 | 119 | single-direction angular-contact thrust ball bearings | ||
7168284. | 420 | 580 | 51,5 | single-direction angular-contact thrust ball bearings | ||
7168436. | 180 | 360 | 32,6 | single-direction angular-contact thrust ball bearings | ||
636905. | 23,5 | 36,5 | 14 | 0,03 | single-row angular contact ball bearings in housing | |
636906. | 28 | 42 | 21,5 | 0,05 | single-row angular contact ball bearings in housing | |
836804. | 19,1 | 32 | 19 | 0,03 | single-row angular contact ball bearings in housing | |
836906. | 28 | 42 | 26 | 0,06 | single-row angular contact ball bearings in housing | |
96605. | 25 | 38 | 12 | 0,03 | single-row angular contact ball bearings in housing | |
986711. | 55 | 90 | 23 | 0,4 | single-row angular contact ball bearings in housing | |
986714. | 70 | 105 | 21 | 0,52 | single-row angular contact ball bearings in housing | |
986811. | 55 | 90 | 22 | 0,33 | single-row angular contact ball bearings in housing | |
116126. | 130 | 200 | 33 | 3,7 | single-row angular-contact double-direction ball bearing | |
116222. | Q222 | 110 | 200 | 38 | 4,87 | single-row angular-contact double-direction ball bearings |
1176720. | 100 | 165 | 30 | 2,7 | single-row angular-contact double-direction ball bearings | |
1176724. | 120 | 200 | 38 | 4,75 | single-row angular-contact double-direction ball bearings | |
1176940. | 200 | 280 | 38 | 6,86 | single-row angular-contact double-direction ball bearings | |
126220. | 100 | 180 | 34 | 3,9 | single-row angular-contact double-direction ball bearings | |
126805. | 25 | 62 | 17 | 0,27 | single-row angular-contact double-direction ball bearings | |
176130. | 150 | 225 | 35 | 4,6 | single-row angular-contact double-direction ball bearings | |
176134. | 170 | 260 | 42 | 8,25 | single-row angular-contact double-direction ball bearings | |
176144. | 220 | 340 | 56 | 20,4 | single-row angular-contact double-direction ball bearings | |
176208. | QJ208 | 40 | 80 | 18 | 0,4 | single-row angular-contact double-direction ball bearings |
176211. | QJ211 | 55 | 100 | 21 | 1 | single-row angular-contact double-direction ball bearings |
176212. | QJ212 | 60 | 110 | 22 | 1 | single-row angular-contact double-direction ball bearings |
176215. | QJ215 | 75 | 130 | 25 | 1,9 | single-row angular-contact double-direction ball bearings |
176218. | QJ218 | 90 | 160 | 30 | 2,68 | single-row angular-contact double-direction ball bearings |
176220. | QJ220 | 100 | 180 | 34 | 3,65 | single-row angular-contact double-direction ball bearings |
176222. | QJ222 | 110 | 200 | 38 | 5,75 | single-row angular-contact double-direction ball bearings |
176226. | QJ226 | 130 | 230 | 40 | 7,2 | single-row angular-contact double-direction ball bearings |
176228. | QJ228 | 140 | 250 | 42 | 8,3 | single-row angular-contact double-direction ball bearings |
176232. | QJ232 | 160 | 290 | 48 | 15,4 | single-row angular-contact double-direction ball bearings |
176234. | QJ234 | 170 | 310 | 52 | 18,7 | single-row angular-contact double-direction ball bearings |
176236. | QJ236 | 180 | 320 | 52 | 17,8 | single-row angular-contact double-direction ball bearings |
176238. | QJ238 | 190 | 340 | 55 | 24,1 | single-row angular-contact double-direction ball bearings |
176240. | QJ240 | 200 | 360 | 58 | 25,1 | single-row angular-contact double-direction ball bearings |
176252. | QJ252 | 260 | 480 | 90 | 81 | single-row angular-contact double-direction ball bearings |
176268. | QJ268 | 340 | 620 | 92 | 128 | single-row angular-contact double-direction ball bearings |
176303. | QJ303 | 17 | 47 | 14 | 0,12 | single-row angular-contact double-direction ball bearings |
176304. | QJ304 | 20 | 52 | 15 | 0,17 | single-row angular-contact double-direction ball bearings |
176305. | QJ305 | 25 | 62 | 17 | 0,24 | single-row angular-contact double-direction ball bearings |
176307. | QJ307 | 35 | 80 | 21 | 0,48 | single-row angular-contact double-direction ball bearings |
176308. | QJ308 | 40 | 90 | 23 | 0,67 | single-row angular-contact double-direction ball bearings |
176309. | QJ309 | 45 | 100 | 25 | 0,9 | single-row angular-contact double-direction ball bearings |
176310. | QJ310 | 50 | 110 | 27 | 0,17 | single-row angular-contact double-direction ball bearings |
176311. | QJ311 | 55 | 120 | 29 | 1,49 | single-row angular-contact double-direction ball bearings |
176313. | QJ313 | 65 | 140 | 33 | 2,3 | single-row angular-contact double-direction ball bearings |
176314. | QJ314 | 70 | 150 | 35 | 2,77 | single-row angular-contact double-direction ball bearings |
176317. | QJ317 | 85 | 180 | 41 | 4,75 | single-row angular-contact double-direction ball bearings |
176320. | QJ320 | 100 | 215 | 47 | 7,74 | single-row angular-contact double-direction ball bearings |
